603X1213 LED Panel Light

GS-P2X4-50/60

Features:



1. Even light distribution

2. LM80-rated-chips ensure color uniformity

3. Dimmable

4. Cool operation

5. Environmental friendly

6. Quality 6063 aluminum frame provide good heat dissipation

7. 50,000 hours life


Inquiry
Specification

Datasheet:




Model
 GS-P2X4-50
 GS-P2X4-60
 GS-P2X4-50
 GS-P2X4-60
Dimension
 603X1213mm
Power
 50W 60W 50W 60W
Lumen
 5,000lm 6,000lm 6,250lm 7,500lm
Lumen Efficiency
 100lm/w 100lm/w 125lm/w 125lm/w
LEDs
 4014 Samsung2835
CCT
 3500K / 4100K / 5000K
CRI
 80Ra
Input Voltage
 120-277V / 50/60Hz
Power Factor
 >0.9
Dimmable
 Designed to be compatible with most 0-10V
Warranty
 5 Years
Frame Color
 White RAL9016
Installtion Way
 Recessed / Suspension / Hanging Installation
Working Temp.
 -20℃ - 50℃




  Package:




Model                  Qty/CTN  CTN Size Net.W Gross.W Qty/20GP'        Qty/40GP'
GS-P2x4 4 pcs 127X27X68cm  36kg 40kg 500pcs 1300pcs








Application:







The LED panel light is applicable for office, school, supermarket, warehouse,etc.
